Rustic – passiv house
About
A passive house with a simple barn shape. It is a house for a 2 + 1 or 2 + 2 family. Large glazing provides perfect lighting of the rooms and gives the possibility of direct exit to the terrace. The entire house is also wheelchair accessible.
The house is made of modules and arrives 90% finished. Set on foundation footings.
Ultimately, it should be ready to move in within a maximum of 6 months from signing the contract.
The glazed wall should be on the south side!
Technology
Rustic is delivered as 6 modules that we connect with each other on the site.
Isover or Rockwool insulation:
floor 280mm (U-0,14)
walls 300mm (U-0.12)
ceiling 400mm (U-0.09)
PVC, 3glass windows – VEKA
Roof – steel welded modular trusses – seam sheet cladding or possibly a tile
The insulation is located in the ceiling which maximizes the insulation effect
Facade – oiled Scandinavian wood – color to choose
Heating
There is a underfloor heating combined with an air-to-water heat pump. The heat pump heats the domestic hot water tank at the same time.
Recuperation is an obvious part of the equipment – central or wall unit.
The estimated energy consumption for 4 people is 23kWh / m? / year, including heating 13kWh / m? / year, so we meet the conditions of a passive house!
Size
- Length 18.70 m
- Width 6.80m
- Height: 6.20 (can be raised)
- Building area: 127m?
- Usable area: 107m?
- Roof: 40 ° angle
- Foundation: footings
Adjustment
The Rustic project can also be produced as an energy-saving house.
It is also possible to mirror view of the building.
It is possible to add a garage, both free-standing and connected to the house.
The design is not for sale, changes to the design must be consulted with our architect.
315 000PLN netto
Included:
Veka 3-glass windows (one-side color), roller blinds and external doors – U-0.8
Scandinavian wood facade
the structure of external walls with C24 45 * 195mm and the structure of the ceiling
roof and flashing – metal sheet
outside, the modules are 100% ready
The client has to do:
electrical and water / drain installations
second structure for external walls made of 45×95 wood
insulation and screwing of drywall or OSB + drywall on the walls and ceiling
dividing walls
all assembly and finishing works inside
408 000PLN netto
Included:
Veka 3-glass windows (one-sided color), roller blinds and external doors – U-0.8
Scandinavian wood facade
ready installations: electric, water, drain
Isover insulation, drywall screwed on OSB
roof and flashing – seam sheet
The client has to do:
painting walls and ceilings
floor panels
installation of interior doors
heating system
bathroom waterproofing and wall and floor cladding
kitchen installation
installation of sockets and lighting
Tetris 67
A small house with a building area of 67m? and an internal area of 57m2. Two bedrooms with built-in wardrobes are not too big, but the living room with the kitchen is large and has large sliding windows. The kitchen has a large window just above the countertop that optically adds space.
Like all modules, Tetris 67 is manufactured in a wood skeleton technology combined with a solid steel frame or it is possible to produce modules without a steel frame.
Technology:
We deliver Tetris as 3 modules that we connect with each other on the site. Standard walls are 25 cm thick, the insulation is 20 cm, the floor has 25 cm of insulation and the roof is 20-30 cm, and of course we can even increase the thickness of the insulation if you wish.
170 000PLN +VAT
Included:
Veka 3-glas windows (one-sided color) and external doors
Scandinavian wood facade
ready water/drain system under the floor with OSB 22mm and Purus shower drain
the structure of external walls with C24 45 * 195mm and the structure of the ceiling
outside, the modules are 100% ready
The client has to do:
electrical installation
insulation and screwing of drywall or OSB + drywall boards on the walls and ceiling
dividing walls
all assembly and finishing works inside
209 000PLN +VAT
Included:
Veka 3-glass windows (one-sided color) and external doors
Scandinavian wood facade
ready electric/water/drain system
Isover insulation, screwed drywall boards
The client has to do:
painting walls and ceilings
floor panels
installation of interior doors
bathroom waterproofing and wall and floor cladding with tiles
kitchen installation
installation of switch sockets and lighting
249 000PLN +VAT
The finished condition includes the finishing of the module at Contma, you can choose the materials yourself, assuming an average standard, so:
floor panels up to PLN 42 net / m2
interior door with a door frame up to PLN 400 net / pc
painting walls and ceilings with Beckers paints
bathroom waterproofing, wall cladding – bathroom panels, floor cladding – Tarkett carpet
Geberit up to PLN 1600 net, washbasin with a cabinet up to PLN 800 net, shower wall up to PLN 1300 net
IKEA kitchen with an under-counter refrigerator, extractor hood, induction hob and microwave up to PLN 5,000 net
It remains for the customer to organize the work on site, such as the foundation, setting the modules, connections, and paying for the crane and transport.
Tetris 102
The building area is 102m? and about 87m2 inside. The entire building is also suitable for a disabled person. Two large bedrooms and a large living room with sliding windows is connected to the kitchen where we can find windows above the countertop. The bathroom is spacious and has space for a washing machine and dryer. We also have an office that we can confidently convert into a bedroom.
40m? living room with kitchen
the bedroom on the left is 12.5m?
bathroom 7.2m?
hall 6.7 m2
office 7.7m?
the bedroom on the right is 12.9m?
Like our other modules, Tetris 102 is manufactured in a wood skeleton technology combined with a solid steel frame, it is possible to produce modules without a steel frame and with a seam roof.
Technology:
We deliver Tetris 102 as 4 modules that we connect with each other on the site. Standard walls are 25 cm thick, the insulation is 20 cm, the floor has 25 cm of insulation and the roof is 20-30 cm, and of course we can increase the thickness of the insulation additionally if you wish.
227 000PLN +VAT
Included:
Veka 3-glas windows (one-sided color) and external doors
Scandinavian wood facade
water/drain system ready under the floor with OSB22mm and Purus shower drain
the structure of external walls with C24 45 * 195mm and the structure of the ceiling
outside, the modules are 100% ready
The client has to do:
electrical installation
insulation and screwing of drywall or OSB + drywall boards on the walls and ceiling
dividing walls
all assembly and finishing works inside
270 000PLN +VAT
Included:
Veka 3-glas windows (one-sided color) and external doors
Scandinavian wood facade
Electric/water/drain systems ready
Isover insulation and drywall screwed
The client has to do:
painting walls and ceilings
floor panels
installation of interior doors
bathroom waterproofing and wall and floor cladding with tiles
kitchen installation
installation of switch sockets and lighting
313 000PLN +VAT
Plug&Play includes the finishing of the module at Contma, you can choose the materials yourself, assuming an average standard, so:
floor panels up to PLN 42 net / m2
interior door with a door frame up to PLN 400 net / pc
painting walls and ceilings with Beckers paints
bathroom waterproofing, wall cladding – bathroom panels, floor cladding – Tarkett carpet or other
Geberit up to PLN 1600 net, washbasin with a cabinet up to PLN 1000 net, bathtub or shower wall up to PLN 1600 net
IKEA kitchen with fridge, dishwasher, extractor hood, induction hob, microwave and stove – up to PLN 16 000 net
It remains for the customer to organize the work on site, such as the foundation, setting the modules, connections, and paying for the crane and transport.
